Zolemera-Zowonjezera Pazipinda Zazipinda za Seva|Malingaliro a kampani FineCo Global
FineCo Heavy-Load Server Room Raised Floor System yapangidwa kuti ikhale-malo ofikira anthu ambiri, zipinda zamaseva amakampani, ndi ntchito-zofunikira kwambiri. Amapangidwa kuti azithandizira katundu wokhazikika kuchokera ku ma seva a blade, mainframes, ndi magawo ogawa mphamvu zolemetsa (PDUs), makinawa amagwiritsa ntchito zida zolimba zotsekeredwa mu chipolopolo chachitsulo chowotcherera.
Zofunika Kwambiri
Kukanika Kwambiri:Zitsulo zowotcherera ndi zolimba zamkati zimalepheretsa kusinthika kosatha pansi pa katundu wokhazikika wopitilira 2,500 lbf (11.1 kN).
Kuwonongeka kwa ESD Kuwongolera:Ma laminates apamtunda amasunga kukana kwamagetsi kosalekeza kwa 1 × 10⁶ mpaka 1 × 10⁹ ohms kuti ateteze zida za IT zodziwika bwino.
Grid Yokhazikika Yokhazikika:Zolemera-zokhala ndi geji ndi bolt{1}}zotsekera ma stringers lock panel kuti zikhale zokhazikika, zomwe zimachotsa kusunthaku ndi kutulutsa mapanelo.
Kulekerera Kuyimilira:Mitu yapazipatso imapereka ± 25 mm yosinthira moyima kuti ibwezere ma subfloor a konkriti osafanana.
Kapangidwe kadongosolo
Kuyika kokwanira kumakhala ndi zigawo zinayi zazikuluzikulu-zosamutsa:
Fikirani Pansi Pansi:Ma modules 600 × 600 mm okhala ndi chitsulo chapamwamba chokhala ndi chitsulo cholimba{2}chowokeredwa ku poto yopangidwa pansi, yodzaza ndi konkire yopepuka kapena apamwamba{3}}kasilsiyamu sulfate.
Pedestal Assemblies:Electro-galvanized steel threaded rods, 100 × 100 × 4 mm base plates, and die-cast head with vibration-daping gaskets.
Bolt-Mu Stringers:Pindani-matchanelo achitsulo okhoma pamitu yazitsulo kuti apange gululi lolimba kuti mutsatire usasunthike.
Zopangira Zozungulira & Gaskets:Zomangira zamakina ndi zotseka-zosindikizira thovu zama cell zomwe zimalepheretsa kutuluka kwa mpweya komanso kupondereza kamvekedwe ka mawu.
Mfundo Zaukadaulo
|
Specification Chinthu |
Standard Steel Panel + Concrete Core |
High-Density Calcium Sulfate Core |
|
Makulidwe a Panel |
600 × 600 × 35 mm |
600 × 600 × 36 mm |
|
Katundu Wokhazikika |
4.45 kN - 11.12 kN (1,000 - 2,500 lbf) |
Mpaka 13.34 kN (3,000 lbf) |
|
Katundu Wofanana (UDL) |
12,000 N/m² mpaka 18,000 N/m² |
16,000 N/m² mpaka 20,000 N/m² |
|
Chitetezo Factor |
Chachikulu kuposa kapena chofanana ndi 3.0 × Ultimate Load |
Chachikulu kuposa kapena chofanana ndi 3.0 × Ultimate Load |
|
Kupatuka kwapakati |
Ochepera kapena ofanana ndi 2.0 mm pamlingo wokhazikika kwambiri |
Ochepera kapena ofanana ndi 1.5 mm pamlingo wokhazikika kwambiri |
|
Kukaniza Pamwamba |
10⁶ - 10⁹ Ω (HPL / Conductive PVC) |
10⁶ - 10⁹ Ω (HPL / Conductive PVC) |
|
Chiyero cha Moto |
Flame Spread 0, Utsi Wapangidwa 0 (ASTM E84) |
Kalasi A / Yosatha{0}}yoyaka (EN 13501-1) |
Seismic Performance
Kugwirizana kwa Frame Frame:Imathandizira ma heavy seismic stringer attachments ndi diagonal cross-bracing for Zone 4 kapena Seismic Design Category D-F compliance.
Kuyesa Kwamphamvu Kwambiri:Kuyesedwa pansi pa cyclic lateral katundu kuti apewe kugwetsa makoma ndikusunga mayendedwe pazochitika za seismic.
Kutseka Kwabwino:Bolt-mu ma stringers amateteza mapanelo kuti asasunthike m'mwamba chifukwa cha kusiyanasiyana kapena kunjenjemera.
Ntchito Zofananira
- Hyperscale ndi Enterprise Data Centers
- Ma Telecommunication Switching Centers
- Network Operations Centers (NOC)
- Zipinda za UPS ndi Battery Backup
- Zipinda Zowonongeka Zamakampani
Kuyika & Kusintha Mwamakonda Anu
Kutalika kwa Floor (FFH):Muyezo wokhazikika kuyambira 300 mm mpaka 1,200 mm kwa ma HVAC plenums apansi ndi ma tray a chingwe.
Perforated Panel:Ma module ogawa ma airflow okhala ndi 25% mpaka 55% malo otseguka ndi ma dampers osinthika.
Cutouts ndi Grommets:Fakitale kapena malo-dulani zingwe zotsegula ndi maburashi kuti mupewe kuwonongeka kwa mpweya.
Kukonzekera kwa subfloor:Pamafunika masitepe a konkire oyeretsedwa otsekedwa ndi anti{0}}fust acrylic sealer asanakhazikitse zitsulo.
Miyezo & Ubwino
CISCA:Njira zokhazikika, zogudubuza, komanso zomaliza zoyezetsa katundu.
EN 12825:Kupititsa patsogolo kagwiridwe ka ntchito ndi ndondomeko zamagulu.
ASTM E84 / UL 723:Makhalidwe oyatsa pamwamba pazomangira.
ISO 9001:2015:Kasamalidwe kabwino kamene kamayang'anira kufufuza zinthu komanso malo odzichitira okha-zololera zowotcherera.
Kupanga & Thandizo la Ntchito
Mphamvu Zopanga:Mizere yodinda yodzichitira yokha komanso zowotcherera za robotic zimapereka zotulutsa mwezi uliwonse zopitilira 100,000 m².
Kufufuza kwazinthu:Zitsulo zochokera ku mphero zokhala ndi malipoti otsimikizika opangidwa ndi mankhwala; kachulukidwe kakang'ono katsimikiziridwa kudzera mu kuyesa kwa batch.
Zojambula Zogulitsa:Gulu laumisiri limapereka mapulani a CAD, ndandanda ya kutalika kwa pedestal, ndi kukhathamiritsa kutengera zojambula zamamangidwe.
Kupaka kwa Logistics:Mapanelo atasanjidwa pa fumigation{0}pallets zaulere zamatabwa, zochepera{1}zokutidwa ndi nembanemba wosalowa madzi, ndi kulimbikitsidwa kuti azinyamula katundu panyanja.
Mafunso Ofunsidwa Kawirikawiri
Q: Kodi ndingadziwe bwanji kuchuluka koyenera kwa chipinda chathu cha seva?
Yankho: Yatsani kusankha kwanu pa kulemera kwa chipangizo chimodzi cholemera kwambiri (monga choyikapo seva yodzaza kwathunthu kapena kabati ya batri) kuphatikiza mphamvu zoyika. Kwa mabizinesi okhazikika ochepera 1,000 kg, makina a CISCA Grade Heavy Load (11.1 kN / 2,500 lbf) okhala ndi calcium sulfate kapena core konkire yolimba akulimbikitsidwa kuti aletse kupatuka kwa gulu pansi pa mawilo a caster.
Q: Kodi pali kusiyana kotani pakati pa mapanelo a konkire-odzazidwa ndi calcium sulfate?
A: Mapanelo a konkriti-odzala ndi zitsulo amapereka kusasunthika kwambiri, kusasunthika, komanso mtengo-mwachangu. Calcium sulfate panels amapereka mpweya wabwino kwambiri, kumvekera bwino kwambiri, kunyamula katundu wambiri, komanso zinthu zina zomwe sizingapse-zikuluzikulu{4}}zosakanizika kwambiri.
Q: Kodi dongosolo kusamalira grounding ndi electrostatic kumaliseche?
A: Mapanelo amalumikizana ndi magetsi kupita ku mitu yapansi kudzera pamagetsi oyendetsa kapena kukhudzana kwachitsulo. Zoyambira zimamangiriridwa mu netiweki ya copper grounding grid pogwiritsa ntchito ma mechanical clamps kapena copper tepi, kusunga njira-ku-kukana kutsika m'kati mwa chitetezo chokhazikika.
Q: Kodi nthawi yotsogolera yoyendetsera ntchito zambiri ndi iti?
A: Nthawi yotsogolera yopangira imachokera masiku 15 mpaka 25, kutengera kuchuluka kwa madongosolo ndi kudulidwa mwamakonda. Zotumizidwa pang'ono zitha kukonzedwa kuti ziperekedwe-zikuluzikulu za data kuti zigwirizane ndi-zochitika zazikulu zomanga malo.
Q: Kodi ma rack olemera a seva angasunthidwe pamakaseti ozungulira pansi pano?
A: Inde. Dongosololi limapirira zolemetsa zomwe zafotokozedwa pansi pa malangizo a CISCA (oyesedwa ndi katundu wa 1,000-lb kupitilira 10,000). Ma hardboard otetezedwa kapena ma track sheet amalimbikitsidwa pakumangirira kolemetsa koyambirira kuti mupewe kukanda pamwamba pa HPL kumaliza.
